Santak PT3KSLI-i Online Rack-mounted UPS 3kVA/3kW

Product details

The Santak UPS PT3KSLI-i Lingxiao Series Uninterruptible Power Supply deeply integrates 30 years of power electronics technology with IoT, providing all-weather power protection for critical equipment. This product adopts an online double-conversion architecture, delivering pure sine wave voltage with ±1% accuracy, effectively eliminating harmonic interference. Its 3kVA/3kW rated power easily supports mainstream IT equipment. The IoT cloud management feature breaks spatial limitations, allowing real-time monitoring of UPS status via a mobile app, customizable anomaly alerts, and multi-level user permission management, making it ideal for cross-regional data center operations teams.The built-in intelligent fan adjusts speed automatically based on load, combined with 93% high-efficiency mode and 97% eco-mode switching, significantly reducing energy costs for data centers. In extreme environments, the PT3KSLI-i demonstrates exceptional adaptability: a 0-50°C wide-temperature operation range ensures stable output in harsh conditions, no power degradation at 3000 meters altitude, and dustproof and corrosion-resistant circuit boards that pass rigorous tests like vibration and humidity, making it particularly suitable for complex scenarios such as industrial plants and remote base stations.For battery management, the product is compatible with both lead-acid batteries and Santak's patented lithium battery system. The latter adopts a three-tier protection architecture, certified by international standards such as IEC62133/UL1642, and paired with a self-developed BMS system for deep UPS integration, tripling the cycle life. In terms of configuration, it comes standard with multiple communication interfaces like USB/RS232/RJ45, supporting Modbus TCP/SNMP protocols for seamless integration into environmental monitoring systems. Four groups of intelligent power distribution sockets enable load-level management, while Santak's IPM power software can trigger virtual machine migration, providing dual protection for cloud computing centers.Whether it's core servers in financial data centers or precision instruments in medical institutions, the PT3KSLI-i redefines power protection standards for critical equipment with its combination of cloud management and robust performance.

Product Features

IoT cloud management: Supports remote monitoring via both APP/Web platforms, enabling real-time fault alerts and multi-level user permission management
High-efficiency design: Online mode conversion efficiency reaches 93%, power factor PF=1 matches IT equipment requirements, reducing electricity costs
Intelligent temperature control: Automatically adjusts fan speed based on load to balance cooling efficiency and noise control
Dual battery compatibility: Supports Santak self-developed lithium batteries and lead-acid batteries, with BMS system providing triple safety protection
Harsh environment adaptability: Operates in 0-50℃ wide temperature range, no derating at 3000m altitude, certified for dustproof, corrosion-resistant, and shockproof performance
Industrial-grade communication protocols: Supports ModbusTCP/RTU and SNMP protocols for seamless integration with environmental monitoring systems
Virtualization compatibility: IPM management software deeply adapts to mainstream virtual platforms like VMware, ensuring secure data migration

Application Scenarios

Network equipment rooms: Connects to environmental monitoring systems via SNMP protocol for centralized intelligent UPS management
Medical facilities: Provides zero-interruption power for CT scanners and life support equipment, meeting medical-grade EMC safety standards
Remote sites: Enables cross-regional maintenance of unmanned base stations/communication equipment through cloud management
Commercial offices: Protects financial systems and security surveillance equipment, supports intelligent load management with 4-zone power distribution
Education/research: Safeguards laboratory precision instruments, lithium battery solution reduces equipment room space occupation

Product Parameters

Model:PT3KSLI-i
Output rated power:3kVA/3kW
Output Power Factor:1
Rated Output Voltage:220V Default (200/208/220/230/240 VAC Optional)
Output Voltage Accuracy:± 1 %
Rated Output Frequency:50Hz/60Hz Adaptive
Output Voltage Total Harmonic Distortion (THDV):<1%
Crest factor ratio:3.1
Online Double Conversion Mode Efficiency @ Full Load:0.93
Eco mode efficiency:0.97
Overload capacity:125%, 10 Minutes
Input Voltage Range:110~300VAC (<160VAC Requires Derating)
Input Frequency Range:45 Hz– 55 Hz (50Hz)/54 Hz – 66 Hz (60Hz)
Input Power Factor (PF):≥ 0.99
Input Current Total Harmonic Distortion (THDi):<5%
Battery Voltage:76.8VDC
Built-in Battery Capacity * Quantity:None
Charging current:6A default (2/4A optional)
Battery Charging Temperature Compensation:Supported
EBM Model:PTLB07228
EBM battery capacity:28Ah
Input Socket:IEC C20
Output Socket:Main Output 1*IEC C19+4*IEC C13 Zone Control Output 4*IEC C13
Display Screen:LCD (Chinese/English)
Communication Interface:Standard USB, RS232, Remote Power On/Off, Smart Slot, Dry Contact, RJ45 (Cloud Connection), Wifi (Optional)
Installation Type:Rack Mount/Tower Installation
UPS * Width * Depth * Height (Rack Mount):438*600*85.5 mm (2U)
UPS Net Weight:11.0kg
EBM Width * Depth * Height (Rack Mount):438*600*85.5 mm (2U)
EBM Net Weight:28.5kg
Operating Environment Temperature:0°C ~ 50°C
Operating Environment Humidity:0 ~ 95% (non-condensing)
Operating Environment Altitude:0~3000 meters
Protection Level:IP20
Certification:TLC, CE, CQC
Warranty Period:5 years
