Santak UPS Power Supply 100KVA Santak SIU 100KVA Industrial UPS Uninterruptible Power Supply
The Santak UPS SIU 100KVA industrial-grade uninterruptible power supply is specifically designed for harsh industrial environments, incorporating over 30 years of power electronics R&D experience to provide stable power support for scenarios like wind power, photovoltaics, and rail transit. With robust features including ultra-wide temperature operation from -25℃ to 60℃, 4000m altitude adaptation, and triple-proof coating technology, it effectively tackles challenges such as grid fluctuations, salt spray corrosion, and low-temperature startups. Supporting dual voltage input of 384VDC/220VDC and equipped with a standard output isolation transformer for device safety, its 3-year full-machine warranty including battery service ensures worry-free maintenance, making it the power guardian expert for renewable energy and outdoor critical equipment.
Buy Now- WeChat：13775032303
- Email：powercube@foxmail.com
Product details
During critical moments when wind turbines face voltage dips, the Santak SIU 100KVA industrial UPS ensures continuous converter operation with zero-millisecond switching speed, strictly complying with the LVRT requirements of the 'Technical Regulations for Wind Farm Integration into Power Systems'. Its ultra-wide input voltage range of 285VAC-498VAC combined with 45-66Hz wide frequency adaptability easily resolves grid fluctuations in wind farms. Key circuit boards feature triple-proof coating technology, enabling stable operation even in coastal wind farms with salt spray concentrations up to 5%.When ambient temperature suddenly drops to -25℃ or rises to 60℃, specially designed power components and redundant circuits maintain full-load output, combined with 384VDC direct busbar technology for higher energy efficiency conversion. For unmanned scenarios like photovoltaic power stations and outdoor energy storage cabinets, the product features a built-in self-management system supporting dry-contact remote monitoring, with dual isolation transformer design effectively blocking grid harmonic interference. Industrial-grade battery packs can be quickly activated even after -40℃ extreme cold storage, while 380V±1% precision voltage regulation at the output provides clean power for pitch control systems. The 125% overload capacity for 10 minutes ensures system safety under sudden load surges.From high-dust workshops in steel plants to 4000m-altitude wind turbine towers, this power fortress with TLC/CE/CQC multi-certification consistently safeguards critical equipment with ≤10% input harmonic distortion, demonstrating industrial power supply's rigorous standards through 90kW true load capacity.Product Features
- Supports ultra-wide operating temperature range (-25°C~60°C) and storage temperature (-40°C~60°C)
- Adapts to high-altitude environments up to 4000 meters, no derating required below 2000 meters
- Redundant design for key components + PCBA triple-proof treatment (moisture, salt spray, mold resistant)
- Ultra-wide input voltage range (285VAC-498VAC), compatible with severe grid fluctuations
- Standard output isolation transformer, optional dual-isolation configuration for enhanced safety
- 3-year warranty covering the entire unit (including battery), supports unattended self-management
- Certified by TLC, CE, and CQC, compliant with LVRT standards for wind power industry
Application Scenarios
- LVRT power protection for wind turbine converters and pitch systems
- Stable power support for photovoltaic inverters and energy storage equipment
- Unattended power supply solutions for outdoor smart terminal cabinets and parcel lockers
- Emergency power backup for rail transit signaling systems and critical equipment
- Industrial equipment protection for high-dust corrosive environments like petrochemical and steel industries
- Reliable operation of outdoor surveying instruments under extreme temperatures and altitudes
- Continuous power supply for intelligent unmanned delivery and outdoor energy storage systems
Product Parameters
- Model:SIU 100KVA Industrial UPS
- Rated Capacity:100KVA
- KVA/KW:100/90
- Applicable power system type:TN-S, TN-C, TN-C-S, TT, IT
- Input/output voltage phase:Three-phase input/three-phase output or single-phase output
- Input voltage range:Mains input: 380/400/415VAC
- Input voltage range:Voltage range: 285VAC-498VAC
- Input frequency range:Rated 50/60Hz, frequency range: 45-66Hz
- Input current harmonic:6-pulse: ≤30%
- Input current harmonic:6-pulse plus 5th filter: ≤10%
- Input current harmonic:12-pulse: ≤10%
- Input power factor:6-pulse: ≥0.8
- Input power factor:6-pulse plus 5th filter: ≥0.92
- Input power factor:12-pulse: ≥0.82
- Battery to mains transfer time:0 ms
- Battery topology:Battery directly connected to DC bus
- Rated battery voltage:DC220V 3/1: (204V,216V,228V)
- Rated battery voltage:DC384V 3/1: (360V,372V,384V,396V,408V)
- Rated battery voltage:DC384V 3/3: (360V,372V,384V) (360V,372V,384V,396V,408V)
- Shared battery at startup:Support
- Output voltage and accuracy:Single-phase: 220V±1% (230V,240V optional)
- Output voltage and accuracy:Three-phase: 380V±1% (400V,415V optional)
- Output frequency and accuracy:Default 50Hz±0.05%. 60Hz optional
- Output voltage harmonic (refer to EN62040-3 standard):<1% @100% linear load
- Output voltage harmonic (refer to EN62040-3 standard):<3% @ 100% non-linear load
- Crest factor ratio:0.125694444
- Overload:<110% rated load, continuous operation
- Overload:110%~125% rated load, 10 minutes
- Overload:125%~150% rated load, 1 minute
